Wifi 6 wireless protocol is supported
Equipped with 1GHz high-end chip, 256MB flash memory 128M memory
All gigabit ports enjoy gigabit network speed, 1800Mbps wireless dual-band signal
MU-MIMO OFDMA technology, lower delay, faster speed
| Model | POWER 20AX |
| Supported standards and protocols | IEEE802.11 b/g/n/ac/ax |
| Port |
1个10/100/1000M Auto MDI/MDIX RJ45 WAN port |
| Forwarding rate | 10/100/1000Mbps |
| Wireless specifications | 2.4G band: 574Mbps; 5G band: 1201Mbps |
| Antenna | 4 high-gain omnidirectional antennas |
| CPU | 1GHz(dual core) |
| RAM | 256MB（Internally packaged in the main IC） |
| ROM | 128MB |
| Button | default×1 |
| LED indicator | PWR、Internet、WIFI、LAN1、LAN2、LAN3、WAN |
| Size | 236mm×144mm×50mm |
| Power supply | 12V/1A |
| Operating environment | Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing |
| Common functions |
Quick configuration |
| Security |
Malicious URL firewall |
| Basic settings |
System upgrade |
| Others |
Emergency recovery |
