Full Gigabit ports, suitable for broadband access over 200M
Built-in PA signal amplifier, longer signal transmission distance
1GHz high-end chip + 128M memory, stable capacity of 80 units
2.4G+5G dual-band integration, whole-house Wi-Fi, seamless roaming
WeChat remote management, more convenient to set parameters
| Product model | POWER 8S black |
| Wireless protocol | IEEE802.11 b/g/n/ac |
| Port |
One 10/100/1000M adaptive WAN port |
| Forwarding rate | 10/100/1000Mbps |
| Wireless specifications | 2.4G band: 300Mbps; 5G band: 867Mbps |
| Antenna | 6根7dBi高增益全向天线 |
| RAM | 128MB |
| ROM | 8MB |
| Button | RESET |
| LED indicator |
1 green and 1 red LED |
| Button | Default |
| Dimensions | 182mm×108mm×25mm（Antenna leveling） |
| Power supply | 12V/1A |
| Operating environment | Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing |
| Common functions | Quick configuration One key speed test Troubleshooting Internet settings Wi-Fi settings Signal conditioning Wireless universal relay Friends only network Child mode Indicator schedule off Wi-Fi schedule off Port mapping Peanut shell dynamic domain name Indicator schedule off Wi-Fi schedule off Internet blacklist Internet host list One-click switch Peanut shell domain name access |
| Security | Malicious URL firewall Internet hijacking firewall Wi-Fi squatter firewall Home network firewall DDos firewall |
| Basic settings |
System upgrade |
| Others | WeChat management Plugin center Emergency recovery |
