Vertical design has more powerful heat dissipation capability
3000M is coming at full speed, Experience the Internet at high speed
160MHz wide bandwidth, double the Internet access rate
Easy Mesh Networking, A green hand turns into an expert soon Simple, concise and poised , Easier for placement,collection and storage
| Product model | POWER 30AX （WiFi6） |
| Product model | IEEE802.11 b/g/n/ac/ax |
| Port |
1* 10/100/1000M RJ45 WAN port
3* 10/100/1000M RJ45 LAN port |
| Forwarding rate | 10/100/1000Mbps |
| Wireless specifications | 2.4G band: 574Mbps; 5G band: 2402Mbps |
| Antenna | 5 high-gain omnidirectional antennas |
| RAM | 256MB |
| ROM | 16MB |
| Button | Reset×1 |
| LED indicator | PWR、Internet、WIFI、LAN1、LAN2、LAN3、WAN |
| Mesh button | Mesh×1 |
| Dimensions | 233mm×164mm×92mm |
| Power supply | 12V/1A |
| Operating environment | Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing |
| Common functions | Connected devices wireless network Internet settings Internal network settings Multiple SSID Signal regulation access control advanced setting MESH networking IPTV WPS remote access Port mapping Port Mirror Dynamic domain name QOS Diagnostic function |
| Basic settings |
Firmware update |
| Others | Mobile web |
