-Easily Fits into the low voltage junction box with a compact sixe of body
-Supports POE power up to 30W for each PoE port ,60W for all POE ports
-Supports POE IEEE 802. 3at/af compliant Powered Device (PD)
-IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
-4KV professional lightning protection, no fear of lightning
-Supports AI Watchdog , 250 meter ethernet extension mode and normal mode
-Steel case, Plug and play, no configuration required
|
Product model |
NS106PE |
| Standard protocol | IEEE802.3af/at series protocol (PD) IEEE802.3 Ethernet Media Access Control Protocol IEEE802.3i 10BASE-T Ethernet IEEE802.3u 100BAST-TX Fast Ethernet IEEE802.3X flow control |
| Port |
4*10/100M POE RJ45 port |
| POE standard |
Standard IEEE802.3AF/AT protocol, the maximum power of a single port is 30W, and the maximum power of the machine is 60W Support overcurrent, overvoltage, short circuit protection Support high power PD soft start Support sequential boot Support certified non-standard PD power receiving |
| Forwarding mode | Store and forward |
| Forwarding rate | 10/100Mbps |
| Backplane bandwidth |
1.2Gbps |
| MAC address table | 2K |
| Default working mode | Normal switch mode/250 meter ethernet extension mode |
| Body Size | 125mm*115mm*34mm |
| Power | AC input 110V-220V |
| Working environment |
Operating temperature: 0°C ~ 40°C Storage temperature: -40°C ~ 70°C Operating humidity: 10% ~ 90%, RH non-condensing Storage humidity: 5% ~ 90%, RH non-condensing |
